Home Electric Vehicle Charger

FLO Home™ EV Chargers

Smart home EV chargers redefining reliability.

Now Available

plug-icon
Home Charge

Installation flexibility to make your job easier.

Flexible Installation

Designed to give electrical contractors more installation options, the new FLO Home can be hardwired directly into the panel with either copper or aluminum wire or plugged into the wall with a NEMA 14-50 plug.

Reliability Redefined

Raising the bar with a 5-year warranty, the FLO Home Level 2 chargers are built to outlast, effortlessly enduring any climate with a durable Type 4X enclosure.

Power

Adjustable amperage

Optimize the electrical panel capacity with our rotary switch that allows you to configure the maximum amperage to be utilized by the charger. Starting at 6A up to 50A or 80A, depending on the model, this feature will cover most of your installation needs.

tail end
plug-icon
For Electricians - API CA-EN

By clicking Submit, you agree to our terms and conditions and privacy policy.

Subscribe now to receive product updates, news, tips, and more!


FLO Home

tail end
Why choose FLO Home EV chargers?

Offer your customers the convenience of fast charging right at their doorstep with the new FLO Home Level 2 charger.

With our adjustable amperage capability, homeowners can benefit from a 50-amp current that delivers up to 12kW of power or an 80-amp current that can provide up to 19.2kW, ensuring their vehicles are ready to go when they are.

Built to outlast

Ultimate peace of mind with an industry-leading 5-year warranty, supported by high-quality components that last for the long term.

Weatherproof
Weather warrior

Braves rain, snow, ice, sea breeze, and dust fearlessly, thanks to its protection by a type 4X enclosure.

Compatible with any EV

Opt for SAEJ1772 or NACS charging connectors and choose your current from 50 amps (power up to 12 kW) to 80 amps (19.2 kW power) that charge most vehicles in less than 8 hours.

Residential Charging
Versatility for any home

Ideal for any setting, indoors or outdoors, and compatible with both copper and aluminum wiring. With subtle lighting and branding, it integrates effortlessly into any environment.

FLO mobile app
Control your charge

The FLO app allow users to set schedules and take advantage of lower utility rates, secure the charger from unintended usage, and see real-time charging status at home and on public charging across North America.

Extensive Warranty
Extra safety protection

Ensures worry-free charging with comprehensive safety certification, heat sensors located in both the NEMA plug* and the connector for potential overheating detection and prevention.

Offer the right charger to your customers

FLO Residential Chargers

FLO HomeTM X3
FLO HomeTM X6
FLO HomeTM X8
Features


Maximum Power & Current: 12 kW @240V / 50A (adjustable from 6 to 50A)
Maximum Power & Current: 19.2 kW @240V / 80A (adjustable from 6 to 80A)
Type 4X Enclosure: Waterproof, impact and corrosion-resistant industrial-grade thermoplastic
Type 4X Enclosure: Waterproof, impact and corrosion-resistant recyclable aluminum
Flexible design: Detachable cable & connector holder
Hardwire: Compatible with copper & aluminum wiring
NEMA 14-50 Plug: Embedded heat sensor & 24 inch cord
Daisy-chain: 2 or more chargers on the same circuit
Compatible with any EV
Flexible, commercial-grade cable: 7.62m (25 ft)
FLO App Smart Features: Restrict Access, Create schedules, charging history, real-time charging status and notifications
Warranty: Industry-leading 5-year
Backed by 15 years of EV charging experience
plug-icon
Looking for a distributor?

Find an authorized distributor so you can get the most out of FLO hardware, software and services.

home
Charged & Ready: Take a Tour of the FLO Home

Explore the product to uncover meticulously crafted design features that elevate your charging experience across any EV from the Nissan Leaf to Tesla Model X.

home
tail end
Technical Specifications
Physical components
  • Enclosure:
    • FLO Home X3: Type 4X, Industrial-grade thermoplastic
    • FLO Home X6 & X8: Type 4X, Recyclable Aluminum
  • Status Indicator: Charging status LED, connectivity status LED
  • Mounting: Wall or pedestal. Wall bracket included.
  • Cable & Connector Holster:
    • FLO Home X3: Fixed
    • FLO Home X6 & X8: Detachable
  • Operating Temperature: -40 °C to 50 °C (-40 °F to 122 °F)
  • Charging Connector:
    • FLO Home X3 & X6: SAE J1772 or NACS, both designed to withstand 10,000+ charging cycles with embedded heat sensors
    • FLO Home X8: SAE J1772 designed to withstand 10,000+ charging cycles with embedded heat sensor
  • Charging Cable: 7.62 m (25 ft) commercial grade
  • Dimensions
    • FLO Home X3: 381 mm x 184 mm x 182.5 mm (15” x 7.25” x 7.188”)
    • FLO Home X6 & X8: 409.4 mm x 208.8 mm x 190.25 mm (16.09” x 8.25” x 7.5”)
  • Weight
    • FLO Home X3
      • Hardwired: 5.6 kg (12.5 lbs)
      • NEMA 14-50: 6.3 kg (13.6 lbs)
    • FLO Home X6
      • Hardwired: 7.8 kg (17.5 lbs)
      • NEMA 14-50: 8.5 kg (18.6 lbs)
    • FLO Home X8
      • Hardwired: 10.2 kg (22.5 lbs)
Electrical specifications
  • Output current:
    • FLO Home X3 & X6: 50 A – adjustable from 6 to 50 A via physical current selector (rotary switch)
    • FLO Home X8: 80 A – adjustable from 6 A to 80 A via physical current selector (rotary switch)
  • Output power:
    • FLO Home X3 & X6: 12 kW
    • FLO Home X8: 19.2 kW
  • AC Input Voltage: 208 – 240 V @ 60 Hz
  • AC Input Connection:
    • FLO Home X3 & X6: NEMA 14-50 with embedded heat sensor, hardwired
    • FLO Home X8: Hardwired only
  • Compatible wiring: Aluminum or copper
  • Wire entry options: Bottom or rear
  • Security: Integrated GFCI 20mA, 3 reset attempts at 15-minute intervals
  • Daisy Chain:
    • FLO Home X3: No
    • FLO Home X6 & X8: Yes
Smart Capabilities & Communication
  • Connection: Wi-Fi 2.4 GHz, Cellular LTE-M*
  • FLO App capabilities: Virtual lock mode, remote start & stop, charging schedule, real-time status, charging history, charging notifications

*Cellular connectivity to the FLO network is a feature in development and may not be enabled at the time of purchase. FLO uses cellular connectivity to administer certain over-the-air product updates and to better understand the location and energy usage of its customers. Please read our privacy policy at www.flo.com/en-ca/privacy-policy to learn about your privacy rights and how we handle personal information.

FLO HomeTM Product documentation
